Source
Light source: 37x 10W RGBW LED mutichips

Led Life Expectancy: minimum 60.000 hours

Typical Lumen Maintenance: 70% @ 60.000 hours

Optical system and effects
Robe’s proprietary optical design

High - efficiency zoom optical system, ratio 8:1

Zoom range: 15° - 60°

Fixture total lumen output: 4.820 lm

Light output: 3.340 lx @ 5 m

Dynamic Effects and Features
Colour mixing mode RGBW

4 individually controllable LED rings

Virtual Colour Wheel: 237 colours including whites (2.700K, 3.200K, 4.200K, 5.600K and 8.000K)

Tungsten lamp effect at whites: 2.700K and 3.200K (red shift and thermal delay)

Colour rainbow effect with variable speed

Pre-programmed random strobe & pulse effects

Electronic strobe effect with variable speed up to 20 Hz

High resolution electronic dimming: 0 - 100%

Control and programming
Setting & Addressing: ROBE Navigation System 2 (RNS2)

Display: QVGA Robe touch screen with battery backup, gravitation sensor for auto screen positioning, operation memory service log with RTC, stand-alone operation with 3 editable programs (each up to 100 steps), built-in analyser for easy fault finding

Protocols: USITT DMX-512, RDM, ArtNet, MA Net, MA Net2

Wireless CRMX™ technology from Lumen Radio

DMX Protocol modes: 6

Control channels: 37, 21, 15, 10, 37, 25

Pan/Tilt resolution: 16 bit

RGBW: 8 or 16 bit

Zoom: 8 bit

Dimmer: 8 or 16 bit

Movement
Pan movement: 450°

Tilt movement: 300°

Automatic Pan/Tilt position correction

Thermal specification
Maximum ambient temperature: 45°C (113°F)

Maximum surface temperature: 75°C (167°F)

Minimum operating temperature: -5°C (23°F)

Electrical specification and connections
Power supply: Electronic auto-ranging

Input voltage range: 100-240 V, 50/60 Hz

Power consumption: Max. 450 W at 230 V / 50 Hz

AC connection: power cable with plug

DMX and RDM data in/out: Locking 3-pin & 5-pin XLR

Ethernet port in: RJ45

Mechanical specification
Height: 444 mm (17.5")

Width: 343 mm (13.5")

Depth: 203 mm (8")

Weight: 10.6 kg (23.4 lbs)
