LIGHT SOURCE TYPE

19 Osram Ostar RGBW LEDs
LED Nominal Wattage: 15W
LED Average Life: 50,000 h
*It may vary depending on various factors, as type of use and environment
PHOTOMETRIC DATA

5,500 lumen
4°-60° Electronic Zoom Range
High efficiency optical system
INPUT POWER

450 VA @230Vac - 50Hz
CONTROL and CONNECTIONS

Control channels: 21/35/57/76
Basic Engine (Standard and Shape Mode).
Pixel Engine (RGB and RGBW Mode).
DMX protocol signal: USITT DMX 512.
Art-Net / RDM / sACN.
Display: Graphic LCD backlit b/w Display
Pan/Tilt Resolution: 16 bit
Dimmer Resolution: 16 bit
Movement control: vectorial
DMX signal connection: 5 pole XLR input and output
Software upload through DMX input
EFFECTS SECTION

Three operating modes: wash, beam, FX (Kaleido effects)
Front Lens Bi-directional Rotation
Digital Wash-Beam Framing effect
Beam edge softening control (in Wash mode)
Pixel Patterning Macros with enhanced control
0-100% linear electronic dimmer
Adjustable speed stop/strobe effect, with instantaneous blackout
Dedicated channel for color temperature setting
White CT Emulation 2500-8000K
RGBW auto-tuning to lamp CT Emulation
Tungsten Lamp Emulation
Slow Strobe: 1 flash/sec; Fast Strobe: 25 flash/sec
Movement:
-PAN = 540° - TILT = 210°
HARDWARE and SOFTWARE

Long-life auto-charging buffer battery
Preset color and graphic effect macros
Function reset controllable from a central control unit
Menu-driven internal self-test function
Art-Net / RDM / sACN.
Display: backlit black-and-white graphic LCD display
Electronic check-up of every single parameter with error alarm
DMX level monitoring on each channel
Automatic internal data transmission error diagnostics
Firmware upgrade even when the unit is not connected to the power supply
Firmware transfer from one light to another
HOUSING

Aluminium structure with die-cast plastic cover
Two side handles for transportation
PAN lock for transport and maintenance

WORKING POSITION

Working in any position
Hanging system: with fast-lock omega clamps (1/4 turn) on the base
ELECTRICAL

Power Supply:100-240V 50/60Hz
450 VA @230Vac - 50Hz
Max Power consumption: 450 VA
SAFETY SPECS

Automatic power safety derating in case of overheat of the LED board.
Forced ventilation
COMPLIANCE

In conformity with the European Directives:
2014/35/EU - Safety of electrical equipment supplied at low voltage (LVD)
2014/30/EU - Electromagnetic Compatibility (EMC)
2011/65/EU - Restriction of the use of certain hazardous substances (RoHS)
2009/125/EC - EcoDesign requirements for Energy-related Products (ErP)
ETL This product it is available, on demand, with cETLus Listed Mark, that complies with the UL 1573, UL 8750 and CSA C22.2 No. 166 standards.
PACKAGING

Carton box + Polystyrene
Carton box + Foam shell
Flight case + Foam shell (4 positions)
WEIGHT - SIZE

15 Kg (33.1 lbs)
ACCESSORIES

Omega clamps: 2x183102/805 (included)
Power cord: CAB03E/802 (included)
Foam shell: F21260  (optional)
Flight case + Foam shell (4 position): F21261 (optional)
