Main features
15.6" monitor

QVGA Robe touch screen with battery backup

4 control jog-wheels

10 preset buttons with a direct access of the pre-programmed features

Activation button

Pan & Tilt freeze buttons

2 faders mounted on the handles with direct control of the key features 0-100% (for example dimmer and iris), assignable to any fixture properties (focus, zoom, frost, etc)

Manual movement control with position indication on the screen

User setting of controllable attributes

Saving and uploading of custom settings

Compatible with: Compatible with the Robe BMFL™ FollowSpot / FollowSpot LT, BMFL™ Spot, BMFL™ Blade, BMFL™ WashBeam, BMFL™ WashBeam EV, ESPRITE®, ESPRITE® FS, iESPRITE®, FORTE®, FORTE® FS, iFORTE®, iFORTE® FS, iFORTE® LTX WB, iFORTE® LTX FS, TX1 PosiProfile™, T1 Profile™, T1 Profile FS™, T2 Profile™, T2 Profile FS™, DL7S Profile™, DL4S Profile™, iSpiider®, iPointe65®, iPointe®, MegaPointe®, Pointe®, SPOTE™, CUETE®, PAINTE®, PAINTE® SPOT, iPAINTE®, ProMotion™, Viva CMY™, SilverScan™, Tarrantula™, Spiider®, LEDBeam 150™, LEDBeam 350™, iBeam 350™, MMX WashBeam™, MMX Blade™, when the RoboSpot MotionCamera is connected to the RoboSpot BaseStation

One RoboSpot can control up to 12 fixtures

Control and programming
Display: QVGA Robe touch screen with battery backup

Movement control: manual

Thermal specification
Maximum ambient temperature: 40°C (104°F)

Minimum operating temperature: 0°C (32°F)

Electrical specification and connections
Power supply: Electronic auto-ranging

Input voltage range: 100-240 V, 50/60 Hz

Power consumption: 15 W

Power in connector: Neutrik powerCON TRUE1

DMX and RDM data in/out: Locking 3-pin & 5-pin XLR

Ethernet port in/out: RJ45

Video inputs
Ethernet port in: RJ45

Mechanical specification
Height: 606 mm (23.8")

Width: 693 mm (27.3")

Depth: 472 mm (18.6")

Weight: 16.5 kg (36.4 lbs)
